Triangle Ebike Battery - Electric Bike Battery with 18650 Cells for Escooter - 36V 48V 52V 20Ah 24Ah 28.8Ah -Triangle Ebike Battery Compatible with 350W 500W 750W 1000W 1500W 1800W Motors
Looking for a reliable and powerful battery for your electric bicycle or scooter? The Triangle Battery is the perfect solution! This battery comes in various voltage and capacity options, including the 36V, 48V, and 52V with capacities of 20Ah, 24Ah, or 28.8Ah. With its high-quality domestic grade A 18650 or Tesla 21700 cells, this battery provides an impressive cycle life of 800-1000 cycles.
The Triangle Ebike Battery is designed to be compatible with a wide range of electric motors, ranging from 250W to 1800W, making it a versatile option for any ebike or escooter. Whether you're using a 350W, 500W, 750W, 1000W, or even a 1500W motor, this battery has got you covered.
This battery is lightweight, weighing in at just 5-6.6kg, depending on the model. It is also designed with durability and safety in mind, featuring a sturdy triangle shape and a reliable Anderson, XT60, or Big Bullet connector. The battery also comes with a charger and discharge connector, ensuring easy and convenient use.
If you're looking for an electric bike battery that's reliable, powerful, and built to last, the Triangle Ebike Battery is the perfect choice. So why wait? Order yours today and experience the joy of hassle-free, long-lasting rides on your electric bicycle or scooter!
4. UnitPackPower batteries have insured to International Insurance, rest assured to buy.
|
Model |
U004 |
||||
|
Parameter |
52V20AH 30A |
52V20AH 40A |
48V20AH 30A |
48V20AH 50A |
36V20AH 25A |
|
Voltage |
52V |
52V |
48V |
48V |
36V |
|
Capacity |
20AH |
20AH |
20AH |
20AH |
20AH |
|
Cell |
Domestic Grade A 2500mAh 18650 Cells |
||||
|
Watt hours |
1040WH |
1040WH |
960WH |
960WH |
720WH |
|
Compitable wattage |
48V/52V 250W 350W 500W 750W 1000W motor |
48V/52V 250W 350W 500W 750W 1000W 1500W |
48V 250W 350W 500W 750W 1000W motor |
48V 250W 350W 750W 1000W 150WW 1800W motor |
36V 250W 350W 500W 700W motor |
|
Dimension |
390*230*355*80 MM |
390*230*355*80 MM |
390*230*355*80 MM |
390*230*355*80 MM |
390*230*355*80 MM |
|
Weight |
appx. 6.6KG |
appx. 6.6KG |
appx. 6.2KG |
appx. 6.2KG |
appx. 5KG |
|
Cycle life |
800-1000 cycle times |
800-1000 cycle times |
800-1000 cycle times |
800-1000 cycle times |
800-1000 cycle times |
|
Charger |
58.8V 2.5A |
58.8V 2.5A |
54.6V 2.5A |
54.6V 2.5A |
42V 3A |
|
Charge cut off voltage |
58.8V |
58.8V |
54.6V |
54.6V |
42V |
|
Discharge current |
30A |
40A |
30A |
50A |
25A |
|
Discharge cut off voltage |
39.2V |
39.2V |
36.4V |
36.4V |
28V |
|
Discharge connector |
Anderson+Paired Anderson |
XT60+Paired XT60 |
Anderson+Paired Anderson |
XT60+ Paired XT60 |
Big Bullet + Paired Big Bullet |
|
Model |
U004 |
U004-1 |
D037 |
||
|
Parameter |
48V 24Ah 50A |
52V 24Ah 40A |
48V 28.8Ah 40A |
52V 28.8Ah 40A |
48V 14Ah 30A |
|
Voltage |
48v |
52V |
48v |
52V |
48v |
|
Capacity |
24Ah |
24Ah |
28.8Ah |
28.8Ah |
14Ah |
|
Cell |
Domestic Grade A 3000mAh 18650 cells |
Tesla 21700 4800mAh cell |
Grade A 3500mAh 18650 |
||
|
Watt hours |
1152WH |
1248WH |
1382.4WH |
1497.6WH |
672WH |
|
Compitable wattage |
48V 250W 350W 500W 750W 1000W 15000W 1800W motor |
52V/48V 250W 350W 500W 750W 1000W 1500W motor |
48V 250W 350W 500W 750W 1000W 15000W motor |
52V/48V 250W 350W 500W 750W 1000W 1500W motor |
48V 250W 350W 500W 750W 1000W motor |
|
Dimension |
390*230*355*80 MM |
390*230*355*80 MM |
390*230*355*81 MM |
390*230*355*81 MM |
350*330*130*60 MM |
|
Weight |
appx. 6.2KG |
appx. 6.6KG |
appx. 6.5KG |
appx. 6.9KG |
appx. 3KG |
|
Cycle life |
800-1000 cycle times |
800-1000 cycle times |
800-1000 cycle times |
800-1000 cycle times |
800-1000 cycle times |
|
Charger |
54.6V 4A |
58.8V 4A |
54.6V 4A |
58.8V 4A |
54.6V 2A |
|
Charge cut off voltage |
54.6V |
58.8V |
54.6V |
58.8V |
54.6V |
|
Discharge current |
50A |
40A |
50A |
40A |
50A |
|
Discharge cut off voltage |
36.4V |
39.2V |
36.4V |
39.2V |
36.4V |
|
Discharge connector |
XT60+Paired XT60 |
XT60+Paired XT60 |
XT60+Paired XT60 |
XT60+Paired XT60 |
Small Anderson |
Which Battery Should I choose?
This really depends on the application and can be a hard question. First you need to get a battery voltage match to your motor request , then the capacity , high capacity can make your bike longer trip but more expensive , also need to choose a right amps BMS to fit your motor . do your research if this is your first ebike kit to make sure you are getting the right battery for your needs.
What cells are your battery packs made up of?
All our packs are made up of authentic Grade A 18650 battery cells made in China , Korea or Japan. We use Sanyo Panasonic Samsung , LG or Chinese A grade brand cells and only use the very best models of these brands. and all of our battery would never
What is a BMS Battery management system?
The circuit board that makes your ebike battery “smart”. All of our packs have state of the art BMS to keep your pack safe.
