TFT display system 48v-72v 3000w electric bike conversion kit sinewave controller 100km/h speed max

Sale price $889.68 Regular price $945.88

TFT display system 48v-72v 3000w electric bike conversion kit sinewave controller 100km/h speed max



Brand Name: NCYCLEBIKE
Voltage: 48v-72v
Design: Brushless
Wattage: > 400w
Motor Type: Brushless Non-gear Hub Motor
Model: NC3000
Power: 48v-72v 3000w
speed: 80-100km/h
N.W: 8.9KGS
rpm: 860@72v
torque: 110N/M
efficiency: 89%
color: black
drop out: 150mm



TFT display system 48v-72v 3000w electric bike conversion kit sinewave controller 100km/h speed max

Note: It is the Colorful UKC1 TFT display with USB Connector.

3.2" high contrast color screen shows battery power level, time, speed, mileage, gear, input power. Components error checking and report.

详情2_副本



New UKC1 TFT colour display 72v 3000w electric bike conversion kit:

1.48V-72V 3000W Electric Bike DIY Conversion Kits Package :

1. 3000W Powerful Brushless Gearless Motorized 20" 24" 26" 700C 28" 29" Wheel Or Motorcycle Wheel 17" 18" 19" 21".
2. 48V-72V 60Amp smart controller
3. Controller bag
4. 1 pair of High Quality Aluminum Alloy Brake Levers
5. Full Twist Throttle
6. PAS 8 Magnets High Quality Pedal Assistant Sensor
7. Book manual and ties
8. UKC1 display with USB port
9. 7speed. (Single speed or six speed is available too)
10. Torque Arm Safe for Customer.
11. GOOD PACKAGE FOR EXPRESS

9



Aluminum alloy Stator



3000w motor drawing



2.Detailed images and specification:

1.48v-72v 3000w ebike motor wheel.

1)Motor voltage:48v -72v 3000w

2)Motor Power:3000w

3)Alex:10mmx M17mm

4)RPM:860@72V

5)Magnet Height:45mm

6)Wings:21x3T

7)Max speed:100km/h @ 72V battery with 29inch wheel.

8)Max torque:110N.m

6)Open size:150mm



2) Different wheels for choose.



3000W Electric Bike Motor Wheel

MTX RIM Details:
1) MTX 24inch, MTX 26inch, MTX 29inch wheels for choose.
2) It is for disc brak​​​​​​e system ONLY.
3) It is double wall aluminum alloy material, good quality.
4) It is good for various tires (1.95, 2.125, 2.1, 2.2, 2.3, 2.5, 3.0).

Motorcycle Rim Details
1) 17inch 18inch 19inch 21inch aluminum alloy rim for choose.
2) It is aluminum alloy material, good quality.
3) It is good for various tires 2.5 2.75 or 3.0


Aluminum alloy Stator



2.Smart Controller with Controller Bag

1) Spec. : 48v-72 60Amp. Max working Voltage 86V.
2) Size: L212mm*W115mm*H55mm
3) Functions: Low Brake, Display, Throttle, Curise, Temperature sensor, lock, 25KPH limited, Pedal Assist Sesor.
With multiple protection features such as stalled, over-current, over-temperature,
over-voltage, under-voltage, speed, lack of phase and so on.
4) Optional Function: Front Light With Horn, Regen.Braking

4
48V-72V 60A 接线图 (2)
3000W 60A 控制器和控制器包
控制器包,力矩臂,7飞

7speed freewheel & Torque Arm. (This is the most Important for safety. Torque arms are used to prevent axle rotation in hub motors. When a hub motor is powered up running, for all the torque that the motor generates spinning a wheel forwards, there is an equal and opposite torque on the axle causing it to rotate backwards.)

torque arm.





3.Brake Lever, Twist Throttle, PAS

1) Aluminum Alloy Material, electric brake & Mechanical braking.
2) Twist Throttle with Grips.
3) 8 magnets 1:1 PAS
刹把, 转把, 助力



5.Packing for 72v 3000w ebike conversion kit:

packing















Features of the Product:


1. High Quality  60A ±1 Controller (Five speed with PAS Function ) , 150Amp phase current
2. 45H V3 3000w BLDC motor
3. Motorcycle & Bicycle rims are choice.
4. Full Speed: about 80-100km/hour
5. Certificates: CE, CCC, ISO 9001-2000



USE for Enduro ebike or Vector bike .

72v 26.1ah batery for 3kw,5kw ebike



FAQ
Q: Custom Duties:
A: Import duties,taxes and charges are not included in the item price .
Q: Color Difference :
A: The pictures showing at our store are taken based on the true products .Because of different monitor and brightness,there may exist normal tiny colour difference,please donnot leave a bad feedback or return goods to us without contacting us
Q: Delivery Time :
A: If products still in Transit ,and your deliver time is going to expire ,kindly contact us ,and we will extend delivery time for you .and if products is lost in transit ,kindly contact us we will make full refund or resend the same products to you soonest .
Q: Feedback:
A:Your satisfaction and positive feedback is very important to us. Please leave positive feedback and 5 stars if you are satisfied with our items and services
If you have any problems with our items or services,please feel free to contact us before you leave negative feedback.
Q: Defective Products:
A: Please do not sign on shipping bill if products is defective , it is shipping company's responsibility , please take photo for us and we will make refund to you .
Q: Return Policy:
A: we do our best to serve our customers.we will refund you if you return the items within 15 days of your receipt of the items and it is only the reason of product itself like defect,damage,anything that is seller's fault,not the buyer's personal preference or failure to use. Besides,the items returned must be in their original conditions
