Manufacturer Custom Automatic Packaging Machine Palletizer Robot Packer 4 Axis Palletizing Robot
low price new HONOR palletizing robot provider($20000/set ) for 50kg bag carton and drum
Honor company produce palletizing robot,and we are also KUKU,ABB,FANUC,KAWASAKI robot agent in China
can provide low price,high quanlity KUKU,ABB,FANUC,KAWASAKI robot line
can provide low price,high quanlity KUKU,ABB,FANUC,KAWASAKI robot line
Product Paramenters
|
|
HR60-2000-PL
|
HN120-2400-PL
|
HN180-3100-PL
|
|
Arm span:
|
2000mm
|
2400mm
|
3100mm
|
|
Repeat positioning accuracy:
|
+0.03mm
|
+0.04mm
|
+0.04mm
|
|
Maximum load:
|
60kg
|
120kg
|
180kg
|
|
Weight:
|
500kg
|
1050kg
|
1120kg
|
|
Installation method:
|
Ground
|
Ground
|
Ground
|
|
Degree of protection:
|
IP54
|
IP54
|
IP54
|
|
Number of axles
|
4 AXIS
|
4 AXIS
|
4 AXIS
|
|
TECHNICAL PARAMETER
|
|
|
|
|
RANGE OE MOTION
|
|
|
|
|
1AXIS
|
±180°
|
±180°
|
±180°
|
|
2 AXIS
|
-35°~+90°
|
-40°~+85°
|
-40°~+90°
|
|
3 AXIS
|
-10°~+110°
|
-20°~+110°
|
-17°~+110°
|
|
4 AXIS
|
±360°
|
±360°
|
±360°
|
|
MAXIMUM SPEED
|
|
|
|
|
1AXIS
|
170°/s
|
105°/s
|
100°/s
|
|
2 AXIS
|
148°/s
|
110°/s
|
95°/s
|
|
3 AXIS
|
185°/s
|
110°/s
|
104°/s
|
|
4 AXIS
|
285°/s
|
290°/s
|
270°/s
|
The features of automatic robot palletizer：
1. Freely programmable, easy to use.
2. Power failure protection function to respond to unexpected situations.
3. Customizable mechanical gripper for final products.
4. High production efficiency, 24/7hours working.
5. End-of-line or central palletizing cells.
6. Empty pallets can be fed with a pallet dispenser or picked by the palletizing robot.
7. Handling of vapor barriers, cap sheets and slip sheets.
8. Handling of multiple pallet sizes.
Q: Can your machine be customized ?
A: Yes, we are a professional manufacturer specilized in palletizing robot, packaging machine, conveyor etc. for more than 10years and we have a strong design&technical team. We can design and manufacture as per your requirements.
Q: How to get an accurate quotation ?
A: Please provide us the detail of the workpiece such as drawing and dimensions.
Q: What's the shipping cost from China to your country ?
A: We can send machine to your port by sea or other term you need. Please kindly tell us your nearest port or address with code.
We have reliable shipping agent to ensure the safe, convenient and timely delivery.
Q: Payment terms, MOQ, warranty, Trade Terms
A: Payment terms: 30% down payment against order by T/T, the balance of 70% to be paid on delivery.
Minimum order quantity: 1 set, FOB Shanghai
Delivery time: about 20-30 working days after receipt of formal order and 30% deposit.
Warranty: 12 months following delivery. We offer online service 24 hours all day long, Skype,
Email etc. You can contact us any time, if urgently, please call us.
A: Yes, we are a professional manufacturer specilized in palletizing robot, packaging machine, conveyor etc. for more than 10years and we have a strong design&technical team. We can design and manufacture as per your requirements.
Q: How to get an accurate quotation ?
A: Please provide us the detail of the workpiece such as drawing and dimensions.
Q: What's the shipping cost from China to your country ?
A: We can send machine to your port by sea or other term you need. Please kindly tell us your nearest port or address with code.
We have reliable shipping agent to ensure the safe, convenient and timely delivery.
Q: Payment terms, MOQ, warranty, Trade Terms
A: Payment terms: 30% down payment against order by T/T, the balance of 70% to be paid on delivery.
Minimum order quantity: 1 set, FOB Shanghai
Delivery time: about 20-30 working days after receipt of formal order and 30% deposit.
Warranty: 12 months following delivery. We offer online service 24 hours all day long, Skype,
Email etc. You can contact us any time, if urgently, please call us.
The Manufacturer Custom Automatic Packaging Machine Palletizer Robot Packer 4 Axis Palletizing Robot is a sensational customer favorite, and we hope you like it just as much.
