Japan Brand Simple Operation Multi-Functional Automatic O/T/C FD-B1445 1.4m Arm Welding Robot
iption
Specification
|
Construction
|
Vertical polyarticular type
|
||
|
Number of axes
|
6
|
||
|
Set reduplication precision
|
+/-0.08mm(Note 1)
|
||
|
Drive system
|
Ac servo motor
|
||
|
Driving energy
|
2900W
|
||
|
Set feed-back
|
Absolute value encoder
|
||
|
Range of action
|
arm
|
J1(rotation)
|
+/-170°(+/-50°)(Note 2)
|
|
J2(front and rear)
|
-155°~ +90°(Note 3)
|
||
|
J3(top and bottom)
|
-170°~ +245°(Note 4)
|
||
|
wrist
|
J4(rotation)
|
+/- 155°(+/- 170°)(Note 5)
|
|
|
J5(Swing)
|
-45°~ +225°(Note 6)
|
||
|
J6(Twist)
|
+/- 205° (+/- 360°)(Note 5、6)
|
||
|
Maximum speed
|
arm
|
J1(rotation)
|
2.97 rad/s {170°/s}(2.27 rad/s {130°/s})(Note 2)
|
|
J2(front and rear)
|
2.97 rad/s {170°/s}
|
||
|
J3(top and bottom)
|
2.97 rad/s {170°/s}
|
||
|
wrist
|
J4(rotation)
|
4.89 rad/s {280°/s}
|
|
|
J5(Swing)
|
4.19 rad/s {240°/s}
|
||
|
J6(Twist)
|
9.08 rad/s {520°/s}
|
||
|
Wrist allows load
|
Moment of force
|
J4(rotation)
|
10.1 N·㎡
|
|
J5(Swing)
|
10.1 N·㎡
|
||
|
J6(Twist)
|
2.9 N·㎡
|
||
|
Moment of inertia
|
J4(rotation)
|
0.38 kg·㎡
|
|
|
J5(Swing)
|
0.38 kg·㎡
|
||
|
J6(Twist)
|
0.03 kg·㎡
|
||
|
The machine and the man act as the model
|
3.57 ㎡ x 340°
|
||
|
Make use of environmental conditions
|
Temperature: 0 ~ 45℃, humidity: 20 ~ 80%RH (no condensation)
|
||
|
Body weight
|
145 kg
|
||
|
Load capacity of upper arm
|
10 kg (Note 7)
|
||
|
Mounted square type
|
Ground, wall hanging, upside down
|
||
|
This body color
|
russet
|
||
Why Choose Us
Packing & Delivery
FAQ
1. who are we?
We are based in Hubei, China, start from 2018,sell to North America(30.00%),Eastern Europe(30.00%),Southern
Europe(20.00%),Africa(10.00%),Domestic Market(10.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
TIG welding machine,Laser welding machine,Gas-bonded Gas welding machine,Welding robots,Welding torch
4. why should you buy from us not from other suppliers?
Wuhan Jinda Welding Technology Co., Ltd. is mainly engaged in the sales and service of high-end welding machines and robots and
their accessories.Agent brands are Panasonic,OTC/Daihen,Beijing Time welder
5. what services can we provide?
Accepted Delivery Terms: FOB,EXW,FCA；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,MoneyGram,Credit Card,PayPal,Western Union;
We are based in Hubei, China, start from 2018,sell to North America(30.00%),Eastern Europe(30.00%),Southern
Europe(20.00%),Africa(10.00%),Domestic Market(10.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
TIG welding machine,Laser welding machine,Gas-bonded Gas welding machine,Welding robots,Welding torch
4. why should you buy from us not from other suppliers?
Wuhan Jinda Welding Technology Co., Ltd. is mainly engaged in the sales and service of high-end welding machines and robots and
their accessories.Agent brands are Panasonic,OTC/Daihen,Beijing Time welder
5. what services can we provide?
Accepted Delivery Terms: FOB,EXW,FCA；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,MoneyGram,Credit Card,PayPal,Western Union;
The Japan Brand Simple Operation Multi-Functional Automatic O/T/C FD-B1445 1.4m Arm Welding Robot was built with people like you in mind. Something to keep you happy Every Single Day.
