SiAECOSYS QSMOTOR 12inch 1000W 72V 45kph Hub Motor with EM30SP controller and kits for Scooter

Regular price $450.00

SiAECOSYSQSMOTOR 12inch 1000W 72V 45kph HubMotor with EM30SP controller and kits for Scooter



For 1000W motor kits, it could be used for Electric Scooter, which could be 72V 45KPH.

e.g. Electric Scooter

Weight, approx 90kg+85kg

Speed: peak 45km/h

Climbing slope: 15 degree@175kg

Tire: 90/90-12



One set including below kits


1. 1pcs X QSMOTOR 12x2.5inch 1000W V1.12 electric wheel hub motor

2. 1pcs X EM30SP sine wave motor controller with standard CAN-BUS

3. 1pcs X  DKD LCD speedometer with CAN (disable CAN as default)

4. 1pcs X Z6 throttle with combination switch




Key Features


1). Simplify to make a electric-scooter. Gearbox, transmission shaft, clutch are no need. Which save space.

2). It could be installed in the rear to save more space for battery.

3). Support regenerative braking

4). High efficiency: 85~92%



Product Description


1. QSMOTOR 12X2.5inch 1000W 260 V1.12 Electric Scooter Hub Motor




2. Drawing




3. Test report



2.  EM30SP72V sinusoidal wave BLDC motor controller



Dimension drawing



3. DKD LCD speedometer, can-bus(optional, LIN as default)


It display D N R, P, S gear, and battery current X5/10.

P.s.: If the working battery doesn't have can-bus communication, then the can-bus speedometer will shows lack of electricity always.

So, we suggest to do the speedometer as Line communication version if client can't get can-bus battery.



4. Z6 throttle with combination switch


With Reverse, Parking button( throttle on/off), 3 slide switch gear, s/boost button, Light and Horn.

It match with VOTOL controller well.



Please noted:


Optional appearance, drawing, performance curve/test report are available.

If you need more technical information, please feel free to contact us.

We will give you reply in 12hours.



Application for 12x2.5inch 3kw in-wheel e-scooter hub motor
