E9 new design red electric car 72V lead acide battery electric car LHD electric vehicle made in china
Products Show
Details Images
Vehicle Model
|
E9 EV
|
|
|
Steering System
|
|
Left
|
|
Dimensions&Specifications
|
|
|
|
Overall dimensions(mm)
|
|
3610*1570*1490
|
|
Wheelbase(mm)
|
|
2345
|
|
Front/Rear Suspension(mm)
|
|
1330/1310
|
|
Tread/Front/Rear(mm)
|
|
1330/1310
|
|
Min.ground clearance(mm)
|
|
145
|
|
Rated Passengers
|
|
5
|
|
Curb Weight(Kgs)
|
|
850
|
|
Power
|
|
|
|
Type of Motor
|
|
AC Motor
|
|
Battery
|
|
Silica gel lead acid maintenance-free battery
|
|
Type of Battery
|
|
12V100Ah/12V120Ah
|
|
Power Consumption(Kwh)
|
|
7.2/8.64
|
|
Drive Form
|
|
Rear Drive
|
|
Mileage(Speed at 30Km)
|
|
120/150
|
|
Max.Torque
|
|
70N·m(3500~4500r/min)
|
|
Max.speed(Km/h)
|
|
55Km/h
|
|
Steering System
|
|
Gear rack mechanical type
|
|
Brake System(Front/Rear)
|
|
Disc/Drum
|
|
Suspension System
|
|
Front:MC Pherson Independent Suspension
|
|
|
|
Rear: Semi drag rocker arm Independent Suspension
|
|
Drive/Brake methods
|
|
Body interior trimming
|
|
Brake system(Front/Rear) Front disc/rear drum The brake booster
|
|
Heating
|
●
|
Drive Method/Rear Drive
|
|
Air Conditioner
|
●
|
Appearance
|
|
Front door electric glass elevator
|
●
|
Self Supporting Body
|
●
|
Rear door electric glass elevator
|
●
|
Bumper
|
●
|
Velvet seat
|
●
|
Electric rearview mirror
|
●
|
Velvet Carpet
|
●
|
Luggage Carrier
|
●
|
Central control lock
|
●
|
Rear fog lamp
|
●
|
Reversing image(large screen)
|
●
|
Antenna
|
●
|
Fire extinguisher
|
●
|
High light inverter
|
●
|
Options(Extra charges)
|
|
Safety Belt
|
●
|
Triangle Safety Warning Board
|
○
|
Colors(White,Cairo Gold,Brown,Pearl Red)
|
●
|
Range Booster
|
○
|
Chassis member
|
|
Electron direction assistance
|
○
|
Power-assisted steering
|
●
|
|
|
Aluminum wheel hub
|
●
|
|
|
Tyre 155/65R 13
|
●
|
|
|
Frontdisc/rear drum brake
|
●
|
|
|
Notes:● for standard,○ for optional,above specifications is according to the object,we'll inform if something is updated
|
The E9 new design red electric car 72V lead acide battery electric car LHD electric vehicle made in china is the product you didn't think you need, but once you have it, something you won't want to live without.
